Intel D865PERL User Manual

Using the BIOS Setup Program
95
ATAPI CD-ROM Drives
Main Advanced Security Power Boot Exit
1st Drive [xxxxxxx]
2
nd
Drive [xxxxxxx]
Specifies the boot
sequence from the
available devices.
Select the boot device
with UpArrow or
DownArrow key. Press
Enter to set the
selections as the
intended boot device.
ARMD = ATAPI Removable
Media Device.
m o
Select Screen
n p
Select Item
Enter
Select ` Sub-Menu
F1 General Help
P9 Setup Defaults
F10 Save and Exit
ESC Exit
The submenu shown in Table 38 is for setting ATAPI CD-ROM drives.
Table 38. ATAPI CD-ROM Drives Submenu
Feature Options Description
1
st
ATAPI CD-ROM Drive
(Note)
Dependent on installed
ATAPI CD-ROM drives
Specifies the boot sequence from the available
ATAPI CD-ROM drives. To specify boot sequence:
1. Select the boot device with <↑> or <↓>.
2. Press <Enter> to set the selection as the
intended boot device.
Note: This boot device submenu appears only if at least one boot device of this type is installed. This list will display
up to four ATAPI CD-ROM drives, the maximum number of ATAPI CD-ROM drives supported by the BIOS.

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
