Intel D865PERL User Manual

11
1 Desktop Board Features
This chapter briefly describes the main features of Intel
®
Desktop Board D865PERL.
NOTE
The board for Desktop Board D865PERL may be either green or black depending on the options
that are included on the board.
Table 1 summarizes the major features of the desktop board.
Table 1. Feature Summary
Processor Support for:
• Intel
®
Pentium
®
4 processor in the mPGA478 package
• Intel
®
Celeron
®
processor the mPGA478 package
Main Memory
• Four 184-pin, 2.5 V SDRAM Dual Inline Memory Module (DIMM) sockets
• 400/333/266 MHz single or dual channel DDR SDRAM interface
• Designed to support up to 4 GB of system memory
NOTE: System resources (such as PCI and AGP) require physical memory address
locations that reduce available memory addresses above 3 GB. This may result in
less than 4 GB of memory being available to the operating system and applications.
For the latest list of tested memory, refer to the Intel World Wide Web site at:
http://support.intel.com/support/motherboards/desktop/
Chipset
• Intel
®
865PE chipset consisting of:
• Intel
®
82865PE Memory Controller Hub (MCH) with Accelerated Hub Architecture
(AHA) bus
• Intel
®
82801ER I/O Controller Hub (ICH5R) supporting Intel
®
RAID Technology or
Intel
®
82801EB I/O Controller Hub (ICH5)
• Firmware Hub (FWH)
Audio
• Intel 865PE chipset (AC ’97)
• Analog Devices Inc. codec
Expansion
Capabilities
• Up to five PCI bus add-in card connectors (SMBus routed to PCI bus 2)
• One AGP 8x, 4x, 1x connector
continued

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
