Intel D865PERL User Manual

Installing and Replacing Desktop Board Components
57
Connecting Hardware Control Cables
See Figure 17 for fan and chassis intrusion header locations. Connect the processor’s fan heat sink
cable to the processor fan header on the board. Connect chassis fan cables to the board fan headers.
Connect the chassis intrusion cable to the respective header on the board.
Connecting Power Cables
CAUTION
Failure to use an ATX12V power supply, or not connecting the 12 V processor core voltage power
supply connector to the desktop board may result in damage to the desktop board and/or power
supply.
Figure 17 shows the location of the power connectors.
1. Observe the precautions in “Before You Begin” on page 27.
2. Connect the 12 V processor core voltage power supply cable to the 2x2 connector.
3. Connect the main power supply cable to the 2x10 connector.

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
