Intel D865PERL User Manual

Using the BIOS Setup Program
93
Hard Disk Drives Submenu
Main Advanced Security Power Boot Exit
1
st
Drive [xxxxxxxxxxxxx]
2
nd
Drive [xxxxxxxxxxxxx]
3
rd
Drive [xxxxxxxxxxxxx]
4
th
Drive [xxxxxxxxxxxxx]
Specifies the boot
sequence from the
available devices.
Select the boot device
with UpArrow or
DownArrow key. Press
Enter to set the
selections as the
intended boot device.
ARMD = ATAPI Removable
Media Device.
m o
Select Screen
n p
Select Item
Enter
Select ` Sub-Menu
F1 General Help
P9 Setup Defaults
F10 Save and Exit
ESC Exit
The submenu shown in Table 36 is for setting hard disk drives.
Table 36. Hard Disk Drives Submenu
Feature Options Description
1
st
Hard Disk Drive
(Note)
Dependent on installed
hard drives
Specifies the boot sequence from the available hard disk
drives. To specify boot sequence:
1. Select the boot device with <↑> or <↓>.
2. Press <Enter> to set the selection as the intended
boot device.
Note: This boot device submenu appears only if at least one boot device of this type is installed. This list will display up to
12 hard disk drives, the maximum number of hard disk drives supported by the BIOS.

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
