Intel Desktop Board D865PERL Product Guide
78
SATA and PATA Submenus
Main Advanced Security Power Boot Exit
` [SATA Port-0 :
Xxxxxxxxx ]
Type [Auto]
Maximum Capacity [Auto]
Configuration Options
Selected By BIOS
LBA Mode : [Supported]
Block Mode : 16 Sectors
PIO Mode : Mode 4
Ultra DMA : Mode 6
m o
Select Screen
Cable Detected : Serial
n p
Select Item
Enter
Select ` Sub-Menu
F1 General Help
P9 Setup Defaults
F10 Save and Exit
ESC Exit
There are six IDE submenus: Two SATA and four PATA (primary master, primary slave,
secondary master, and secondary slave). Table 23 shows the format of these IDE submenus. For
brevity, only one example is shown.
Table 23. SATA and PATA Submenus
Feature Options Description
Drive Installed
None
Displays the type of drive installed.
Type • Auto (default)
• User
Specifies the IDE configuration mode for IDE devices.
Auto fills-in capabilities from ATA/ATAPI device.
User allows capabilities to be changed.
Maximum Capacity
None
Displays the capacity of the drive.
LBA Mode Control
(Note)
None
Specifies LBA mode control.
Block Mode • Disabled
• Auto (default)
Check the hard disk drive’s specifications for optimum
setting.
PIO Mode
(Note)
• Auto (default)
• 0
• 1
• 2
• 3
• 4
Specifies the PIO mode.
continued

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
