Intel Desktop Board D865PERL Product Guide
76
Table 21. Peripheral Configuration Submenu (continued)
Feature Options Description
Mode
• Output only
• Bi-directional
(default)
• EPP
• ECP
Selects the mode for the parallel port. Not available if
the parallel port is disabled.
Output Only operates in AT*-compatible mode.
Bi-directional operates in PS/2-compatible mode.
EPP is Extended Parallel Port mode, a high-speed
bi-directional mode.
ECP is Enhanced Capabilities Port mode, a high-speed
bi-directional mode.
Base I/O Address
(This feature is present
only when Parallel Port
is set to Enabled)
• 378 (default)
• 278
Specifies the base I/O address for the parallel port, if
Parallel Port is Enabled.
Interrupt
(This feature is present
only when Parallel Port
is set to Enabled)
• IRQ 5
• IRQ 7 (default)
Specifies the interrupt for the parallel port, if Parallel Port
is Enabled.
Audio
• Enabled (default)
• Disabled
Enables or disables onboard audio.
Onboard LAN
(This feature is present
only when there is
onboard LAN)
• Disabled
• Enabled (default)
Enables or disables the onboard LAN.

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
