Modular Server System Service Guide 99
Physical Drives
The Modular Server System has an integrated hard disk drive bay. Storage is shared
among all installed servers by grouping physical drives together into storage pools, and
then creating virtual drives that are then assigned to individual servers.
To view current status, available actions and product details for all installed hard drives,
select a specific hard drive from the system graphic. The selected hard drive will be
highlighted on the system graphic. The action box, help box and informational tabs will
update to provide all available actions and information for the selected hard drive. Current
health and product summary is quickly available by moving the mouse over the Health/
Information icon located on the selected hard drive.
Note: For drives that are included in a storage pool, limited drive details are also displayed on
the physical drive tab for the assigned storage pool.
Figure 63. Physical Drives
