Intel MFSYS25V2 Service Guide

Intel
®
Modular Server System Service Guide 35
4. Press the power supply module retention latch to release the power supply module
from the bay (see letter “A” in Figure 22). Slide the power supply module out of the
module bay (see letter “B” in Figure 22).
Figure 22. Removing a Power Supply Module
5. Replace the power supply module with a filler panel or another power supply module
within two minutes.
Replacing a Main Cooling Module
The Intel
®
Modular Server System MFSYS25/MFSYS35 ships with two main cooling
modules pre-installed at the back of the chassis. For the exact location of the Main
Cooling Modules, see Figure 5.
AF002433
B
A
