Modular Server System Service Guide 31
3. Place the storage control module sideways on a work surface so that its largest surface
area is touching the work surface and the retention lever is on the top.
4. With a Phillips* screwdriver, remove the screw securing the top cover to the storage
control module (see letter “A” in Figure 18).
Figure 18. Removing Top Cover from Storage Control Module
5. Slide the cover towards rear of the storage control module (see letter “B” in
Figure 18) and lift upward (see letter “C” in Figure 18).
A
B
C
AF002563
