Modular Server System Service Guide
Table 20. Health Icons
Intel
®
Gigabit Ethernet Switch Module Actions
The actions available for a selected switch module are displayed to the right of the system
graphic. For a description of these actions, refer to the following table.
Table 21. Switch Module Action Menu
Health Icon Meaning
Critical (For details, see the Event Log. For information about
accessing the Event Log, see “Events” on page 122.)
Warning (For details, see the Event Log. For information about
accessing the Event Log, see “Events” on page 122.)
Information
OK
Firmware update or other background activity
Action Menu Item Description
Configure Ports Configures port and Virtual LAN (VLAN) settings
within the Intel
®
Modular Server Control UI. This
action provides quick access to frequently
configured port and VLAN options.
Reset Enables remote reset of the selected switch
module.
Advanced Configuration Launches a third-party Advanced Switch
Configuration interface in a new window to view all
switch configuration options. Refer to the Intel
®
Gigabit Ethernet Switch AXXSW1GB User Guide
for more information on how to use the Advanced
Configuration Switch interface.
