Modular Server System Service Guide 3
Table 1. Modular Server System Features
Intel® Modular Server Systems Content and References
The following three versions of the Intel
®
Modular Server System are available:
• Intel
®
Modular Server System MFSYS25
• Intel
®
Modular Server System MFSYS35
• Intel
®
Modular Server System MFSYS25V2
Intel
®
Modular Server System MFSYS25 Contents
Your Intel
®
Modular Server System MFSYS25 ships with the following items:
Feature Description
Chassis Dimensions
• 10.3 inches (261.4 mm) high – 6U
• 17.5 inches (444.4 mm) wide
• 28.4 inches (720.2) mm long
• 187 lbs (85 kg) - maximum full configuration weight
Module Bays (rear) • Four hot-plug 110/220V power module bays
• Two hot-swap Ethernet switch module bays
• Two hot-swap storage control module bays
• Two hot-swap main cooling module bays
• One hot-swap management module bay
Module Bays (front) • Six hot-plug compute module bays
• One hot-swap I/O cooling module bay
• One hard disk drive bay
Hard Disk Drive Bay • Intel
®
Modular Server System MFSYS25: 14 hot-swap 2.5-
inch SAS hard disk drive carriers with filler blanks installed
(hard disk drives are NOT included)
• Intel
®
Modular Server System MFSYS35: 6 hot-swap 3.5-
inch SAS or SATA hard disk drive carriers with filler blanks
installed (hard disk drives are NOT included)
Intel
®
Modular Server Control • Powerful integrated management GUI for configuration and
chassis management
• Provides a single interface for system updates
Table 2. Intel
®
Modular Server System MFSYS25 Contents
Quantity Description
One Chassis enclosure
One Intel
®
Management Module
One Intel
®
Gigabit Ethernet Switch Module
One Intel
®
Storage Control Module
To Next Page
