Intel MFSYS25V2 Service Guide

Intel
®
Modular Server System Service Guide 41
4. Align the holes in the hard drive to the holes in the drive carrier (see letter “A” in
Figure 28) and attach it to the drive carrier using the four screws removed in the
previous step (see letter “B” in Figure 28).
Figure 28. Installing Hard Drive into Drive Carrier
AF002428
B
A
