Intel
®
Modular Server System Service Guide 107
Intel
®
Gigabit Ethernet Switch Details
The tabs displayed below the system graphic provide detailed information for the selected
switch module. For a description of these tabs, refer to the following table.
Table 22. Switch Module Tabs
Intel
®
Gigabit Ethernet Switch Module Help
To quickly access additional help regarding the Intel
®
Gigabit Ethernet Switch Module
screen, actions, and tabs, click on the Get Help button in the Switch help box located
under the Actions box.
Configuring an Intel
®
Gigabit Ethernet Switch
Intel
®
Gigabit Ethernet Switches come pre-configured with all available ports enabled in
a single default VLAN. No additional configuration is required to connect the Intel
®
Modular Server System MFSYS25/MFSYS35 to a network.
Two options are available to modify the default switch configuration:
• The Configure Ports action menu item enables an IT administrator to quickly and
easily modify port and Virtual LAN (VLAN) settings. Figure 66 displays the
Configure Ports dialog box within the Intel
®
Modular Server Control UI.
• To make additional changes to the switch configuration, click Advanced
Configuration in the Actions menu. The Advanced Configuration action launches a
separate switch configuration interface in a new window. Refer to the Intel
®
Gigabit
Ethernet Switch AXXSW1GB User Guide for more information on how to use the
Advanced Configuration.
Tab Heading Description
General Displays current status and general Intel
®
Gigabit Ethernet Switch
information, such as product ID, uptime, hardware and software versions,
and MAC address.
Events Displays all system events for the selected Intel
®
Gigabit Ethernet
Switch.
Ports Displays table of key port settings, including Port ID, VLAN ID, Enabled/
Disabled Status, Link Status, Set Speed, Current Speed, VLAN Mode,
and Spanning Tree (STP).
VLANs (Virtual
LANs)
Displays a table of configured VLANs for the selected switch, including
VLAN number, VLAN name, and members.
Statistics Displays a table of statistics for the selected switch, including Port ID,
Input, Output, and Error Information.
