Modular Server System Service Guide 119
Table 30. Health Icons
Intel
®
Modular Server Fans and Power Supplies Details
The tabs displayed below the system graphic provide detailed information for the selected
fan or power supply. For a description of these tabs, refer to the following table.
Table 31. Fans and Power Supplies Tabs
Reports
The Intel
®
Modular Server Control generates several standard reports. These reports are
used by IT administrators to view overall system health, system configuration
information, event logs, diagnostic information, storage resource allocation map, switch
performance, and hardware and firmware inventory. The following reports are supported:
Storage Layout, Events, Dashboard, and Diagnostics.
Health Icon Meaning
Critical (For details, see the Event Log. For information about
accessing the Event Log, see “Events” on page 122.)
Warning (For details, see the Event Log. For information about
accessing the Event Log, see “Events” on page 122.)
Information
OK
Tab Heading Description
General The General tab displays:
• Current status of the selected fan or power supply (i.e., status,
health)
• Product data table will display information, including manufacturer,
model number, serial number, etc.
Events Displays all events for the selected fan or power supply.
Sensors Displays current sensor information, including fan speed, input/output
power, temperature, etc.
