Legacy Fan Speed Control
Thermal and Mechanical Design Guidelines 107
spike smoothing). Please select the lowest setting available close to 4.0 seconds by the
fan speed control device
4. The Fan Speed Controller, or Health Monitor Component, takes the result of the two fan
speed ramps (processor and system) and drives the TMA fan to the highest resulting
PWM duty cycle (%)
5. For BTX systems a second thermal sensor is recommended to capture chassis ambient
for more detail see
Appendix F.
6. To ensure compliance with the thermal specification, thermal profile and usage of the
T
SENSOR
for fan speed control these setting should not be user configurable.
7. If this function is present on the device it must be enabled
Note: The fan speed component vendors provide libraries that are used by the BIOS writer
to program the component registers with the parameters listed above. Consult the
appropriate vendor datasheet for detailed information on programming their
component.
§

Intel QX9770 - Core 2 Extreme Quad-Core Processor Specifications

General

Processor Number	QX9770
Number of Cores	4
Thread Count	4
Clock Speed	3.2 GHz
L2 Cache	12 MB
Bus Speed	1600 MHz
Thermal Design Power (TDP)	136 W
Socket	LGA 775
Manufacturing Process	45 nm
Max Operating Temperature	64.5°C
Virtualization Technology	Yes
64-bit Support	Yes
Instruction Set	SSE4.1
Memory Channels	2
Memory Types	DDR3
