Intel QX9770 - Core 2 Extreme Quad-Core Processor - Figure 65. Thermal Sensor Location Illustration

BTX System Thermal Considerations
Thermal and Mechanical Design Guidelines 111
Figure 65. Thermal sensor Location Illustration
T
M
A
Air
f
l
o
w
Thermal
Sensor
MCH Heatsink
§
