Intel® Server Board S1200V3RP TPS BIOS Setup Interface
Revision 1.2
If the SATA Controller is Disabled, the SATA Ports will not operate, and any installed
SATA devices will be unavailable.
Compatibility provides PATA emulation on the SATA device, allowing the use of legacy
IDE/PATA drivers.
Enhanced provides Native SATA support using native SATA drivers included with the
vast majority of current OSes.
AHCI enables the Advanced Host Controller Interface, which provides Enhanced SATA
functionality plus possible additional functionality (Native Command Queuing, Hot Plug,
Staggered Spin Up). It uses AHCI drivers available for the majority of current OSes.
RAID Mode provides host based RAID support on the onboard SATA ports. RAID levels
supported and required drivers depend on the RAID stack selected
Back to [Mass Storage Controller Configuration Screen] — [Screen Map]
2. AHCI Capable RAID Options
Option Values: Intel(R) ESRT2 (LSI*)
Intel(R) RSTe
Help Text:
Intel(R) ESRT2 (Powered by LSI*): Supports RAID 0/1/10 and optional RAID 5 with
Intel
®
RAID C220 Upgrade Keys. Uses Intel ESRT2 drivers (based on LSI* MegaSR).
Intel(R) RSTe: Provides pass-through drive support. Also provides host based RAID
0/1/10/5 support. Uses Intel(R) RSTe iastor drivers.
Comments: This option only appears when the SATA Controller is enabled,
and RAID Mode has been selected as the operational SATA Mode. This setting selects
the RAID stack to be used for SATA RAID with the onboard AHCI SATA controller.
If a RAID Volume has not previously been created that is compatible with the RAID stack
selected, it will be necessary to Save and Exit and reboot in order to create a RAID
Volume.
Note: This option does not appear on all boards.
Back to [Mass Storage Controller Configuration Screen] — [Screen Map]
3. Intel(R) Storage Module
Option Values: None
<Name of Storage Module detected>
Names of Storage Modules supported at this time are:
