Intel S1200V3RP Technical Product Specification

BIOS Setup Interface Intel® Server Board S1200V3RP TPS
Revision 1.2
120
Intel(R) Integrated RAID Module
Intel(R) Integrated RAID Module RMS25PB040
Intel(R) Integrated RAID Module RMT3PB080
Intel(R) Integrated RAID Module RMS25CB080
Intel(R) Integrated RAID Module RMS25CB040
Intel(R) Integrated RAID Module RMT3CB080
Intel(R) Integrated RAID Module RMS25JB080
Intel(R) Integrated RAID Module RMS25JB040
Intel(R) Integrated RAID Module RMS25KB080
Intel(R) Integrated RAID Module RMS25KB040
Help Text: <None>
Comments: Information only. If no Intel
®
Storage Module is detected, then
None is displayed. This shows the customer the product name of the module installed,
which helps in identifying drivers, support, documentation, etc.
Back to [Mass Storage Controller Configuration Screen] — [Screen Map]
4. SATA Port (For Port numbers 0-6)
Option Values: Not Installed
<Drive Information>
Help Text: <None>
Comments: Information only. The Drive Information, when present, will
typically consist of the drive model identification and size for the disk drive installed on a
particular port.
This Drive Information line is repeated for all 6 SATA Port for the onboard AHCI capable
SATA Controller. However, for any given board, only the ports which are physically
populated on the board are shown. That is, a board which only implements the two 6
GB/s ports 0 and 1 will only show those two ports in this Drive Information list.
Back to [Mass Storage Controller Configuration Screen] — [Screen Map]
9.4.2.7 PCI Configuration
The PCI Configuration screen allows the user to configure the PCI memory space used for
onboard and add-in adapters, configure video options, and configure onboard adapter options.
