Intel S1200V3RP Technical Product Specification

Intel® Server Board S1200V3RP TPS BIOS Setup Interface
Revision 1.2
127
Option Values: Enabled
Disabled
Help Text:
Enables or disables PCI PME function for Wake on LAN capability from LAN adapters.
Comments: Enables/disables PCI/PCIe PME# signal to generate Power
Management Events (PME) and ACPI Table entries required for Wake on LAN (WOL).
However, note that this will enable WOL only with an ACPI-capable Operating System
which has the WOL function enabled.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
— [Screen Map]
2. PXE 1GbE Option ROM
Option Values: Enabled
Disabled
Help Text:
Enable/Disable Onboard/IOM NIC PXE Option ROM Load.
Comments: This selection is to enable/disable the 1GbE PXE Option ROM
that is used by all Onboard and IO Module 1 GbE controllers.
This option is grayed out and not accessible if the iSCSI Option ROM is enabled. It can
co-exist with the 10 GbE PXE Option ROM, the 10 GbE FCoE Option ROM, or with an
InfiniBand controller Option ROM.
If the 1GbE PXE Option ROM is disabled, and no other Option ROM is enabled, the
system cannot perform a Network Boot and cannot respond for Wake-on-LAN.
This 1GbE PXE option does not appear unless there is a 1 GbE NIC installed in the
system as an Onboard or IO Module NIC.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
— [Screen Map]
3. PXE 10GbE Option ROM
Option Values: Enabled
Disabled
Help Text:
Enable/Disable Onboard/IOM NIC PXE Option ROM Load.
