Intel S1200V3RP Technical Product Specification

BIOS Setup Interface Intel® Server Board S1200V3RP TPS
Revision 1.2
128
Comments: This selection is to enable/disable the 10GbE PXE Option ROM
that is used by all Onboard and IO Module 10 GbE controllers.
This option is grayed out and not accessible if the iSCSI Option ROM is enabled or the
10 GbE FCoE Option ROM is enabled. It can co-exist with the 1 GbE PXE Option ROM
or with an InfiniBand controller Option ROM.
If the 10GbE PXE Option ROM is disabled, and no other Option ROM is enabled, the
system cannot perform a Network Boot and cannot respond for Wake-on-LAN.
This 10GbE PXE option does not appear unless there is a 10 GbE NIC installed in the
system as an Onboard or IO Module NIC.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
— [Screen Map]
4. FCoE 10GbE Option ROM
Option Values: Enabled
Disabled
Help Text:
Enable/Disable Onboard/IOM NIC FCoE Option ROM Load.
Comments: This selection is to enable/disable the 10GbE FCoE Option ROM
that is used by all Onboard and IO Module 10 GbE controllers capable of FCoE support.
At the present time, only the Intel
®
82599 10 Gigabit SFP+ NIC supports FCoE for this
family of server boards.
This option is grayed out and not accessible if the 10GbE PXE Option ROM is enabled
or if the iSCSI Option ROM is enabled. It can co-exist with the 1GbE PXE Option ROM
or with an InfiniBand controller Option ROM.
If the FCoE Option ROM is disabled, and no other Option ROM is enabled, the system
cannot perform a Network Boot and cannot respond for Wake-on-LAN.
This FCoE option does not appear unless there is a FCoE-capable 10GbE NIC installed
in the system as an Onboard or IO Module NIC.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
— [Screen Map]
5. iSCSI 1GbE/10GbE Option ROM
Option Values: Enabled
Disabled
Help Text:
