Intel® Server Board S1200V3RP TPS BIOS Setup Interface
Revision 1.2
Enable/Disable Onboard/IOM NIC iSCSI Option ROM Load.
Comments: This selection is to enable/disable the iSCSI Option ROM that is
used by all Onboard and IO Module 1 GbE and 10 GbE controllers.
This option is grayed out and not accessible if the 1 GbE or 10GbE PXE Option ROM is
enabled or if the 10 GbE FCoE Option ROM is enabled. It can co-exist with an InfiniBand
controller Option ROM.
If the iSCSI Option ROM is disabled, and no other Option ROM is enabled, the system
cannot perform a Network Boot and cannot respond for Wake-on-LAN.
This iSCSI option does not appear unless there is an iSCSI -capable NIC installed in the
system as an Onboard or IO Module NIC.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
— [Screen Map]
6. Onboard NIC1 Type
7. Onboard NIC2 Type
Option Values: <Onboard NIC Description>
string:
Intel(R) I210 Dual-Port Gigabit Ethernet Controller
Help Text: <None>
Comments: Information only. This is a display showing which NICs are
available as Network Controllers integrated into the baseboard. Each of these Onboard
NICs will be followed by a section including a group of options that are specific to the
type of NIC, either as an Ethernet controller or an InfiniBand controller.
If a board only has one onboard NIC, the second NIC Type and following options section
will not appear.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
— [Screen Map]
8. IO Module 1 Type
9. IO Module 2 Type
Option Values: <IO Module Description>
One of these strings:
Intel(R) I350 Quad-Port Gigabit Ethernet Module
Intel(R) I540 Dual-Port X540 10 Gigabit RJ-45 Module
