Intel® Server Board S1200V3RP TPS BIOS Setup Interface
Revision 1.2
171
Back to [BMC LAN Configuration Screen] — [Server Management Screen] — [Screen
Map]
13. Subnet Mask
Option Values: [Entry Field 0.0.0.0, 0.0.0.0 is default]
Help Text:
View/Edit Subnet Mask. Press <Enter> to edit.
Comments: This specifies the IPv4 addressing Subnet Mask for the Intel®
RMM4 DMN LAN. There is a separate IPv4 Subnet Mask field for the Baseboard LAN
configuration.
When IPv4 addressing is used, the initial value for this field is acquired from the BMC.
The setting of IP Source determines whether this field is display-only (when Dynamic) or
can be edited (when Static).
When IPv6 addressing is enabled, this field is grayed out and inactive.
Back to [BMC LAN Configuration Screen] — [Server Management Screen] — [Screen
Map]
14. Gateway IP
Option Values: [Entry Field 0.0.0.0, 0.0.0.0 is default]
Help Text:
View/Edit Gateway IP. Press <Enter> to edit.
Comments: This specifies the IPv4 addressing Gateway IP for the Intel®
RMM4 DMN LAN. There is a separate IPv4 Gateway IP field for the Baseboard LAN
configuration.
When IPv4 addressing is used, the initial value for this field is acquired from the BMC.
The setting of IP Source determines whether this field is display-only (when Dynamic) or
can be edited (when Static).
When IPv6 addressing is enabled, this field is grayed out and inactive.
Back to [BMC LAN Configuration Screen] — [Server Management Screen] — [Screen
Map]
15. IPv6 Source
Option Values: Static
Dynamic
Auto
