BIOS Setup Interface Intel® Server Board S1200V3RP TPS
Revision 1.2
When an Intel
®
RMM4 + DMN is installed, the options for Intel
®
RMM4 LAN
Configuration will be visible. When IPv6 is Disabled, the IPv4 configuration fields will be
visible and the IPv6 configuration fields will not be visible. When IPv6 is Enabled, the
IPv4 fields will be grayed out and inactive, while the IPv6 Configuration fields will be
visible.
In either case, the Intel
®
RMM4 section IP Source or IPv6 Source will determine whether
the IPv4 or IPv6 address fields are display-only or can be edited.
Back to [BMC LAN Configuration Screen] — [Server Management Screen] — [Screen
Map]
11. IP Source
Option Values: Static
Dynamic
Help Text:
Select RMM4 IP source: If [Static], IP parameters may be edited. If [Dynamic], these
fields are display-only and IP address is acquired automatically (DHCP).
Comments: This specifies the IP Source for IPv4 addressing for the Intel
®
RMM4 DMN LAN connection. There is a separate IP Source field for the Baseboard LAN
configuration.
When IPv4 addressing is used, the initial value for this field is acquired from the BMC,
and its setting determines whether the other Intel
®
RMM4 DMN LAN IPv4 addressing
fields are display-only (when Dynamic) or can be edited (when Static).
When IPv6 addressing is enabled, this field is grayed out and inactive.
Back to [BMC LAN Configuration Screen] — [Server Management Screen] — [Screen
Map]
12. IP Address
Option Values: [Entry Field 0.0.0.0, 0.0.0.0 is default]
Help Text:
View/Edit IP Address. Press <Enter> to edit.
Comments: This specifies the IPv4 Address for the Intel
®
RMM4 DMN LAN.
There is a separate IPv4 Address field for the Baseboard LAN configuration.
When IPv4 addressing is used, the initial value for this field is acquired from the BMC.
The setting of IP Source determines whether this field is display-only (when Dynamic) or
can be edited (when Static).
When IPv6 addressing is enabled, this field is grayed out and inactive.
To Next Page
