Intel® Server Board S1200V3RP TPS BIOS Setup Interface
Revision 1.2
View/Edit Gateway IPv6 address. Press <Enter> to edit. Gateway IPv6 addresses
consist of 8 hexadecimal 4 digit numbers separated by colons.
Comments: This specifies the Gateway IPv6 Address for the Baseboard LAN.
There is a separate Gateway IPv6 Address field for the Intel
®
RMM4 LAN configuration.
This option is only visible when the IPv6 option is set to Enabled.
When IPv6 addressing is used, the initial value for this field is acquired from the BMC.
The setting of IPv6 Source determines whether this field is display-only (when Dynamic
or Auto) or can be edited (when Static).
Back to [BMC LAN Configuration Screen] — [Server Management Screen] — [Screen
Map]
9. IPv6 Prefix Length
Option Values: [Entry Field 0 – 128, 64 is default]
Help Text:
View/Edit IPv6 Prefix Length from zero to 128 (default 64). Press <Enter> to edit.
Comments: This specifies the IPv6 Prefix Length for the Baseboard LAN.
There is a separate IPv6 Prefix Length field for the Intel
®
RMM4 LAN configuration.
This option is only visible when the IPv6 option is set to Enabled.
When IPv6 addressing is used, the initial value for this field is acquired from the BMC.
The setting of IPv6 Source determines whether this field is display-only (when Dynamic
or Auto) or can be edited (when Static).
Back to [BMC LAN Configuration Screen] — [Server Management Screen] — [Screen
Map]
10. Intel(R) RMM4
Option Values: Not Present
Intel(R) RMM4-Lite
Intel(R) RMM4 + DMN
Help Text: <None>
Comments: Information only. Displays whether an Intel
®
RMM4 component is
currently installed. This information may come from querying the BMC.
Intel
®
RMM4-Lite is the Management Module without the Dedicated Server Management
NIC Module. When this is present, or if the Management Module is Not Present at all,
the fields for Intel
®
RMM4 LAN Configuration will not be visible.
