Zero Channel RAID
The SE7501HG2 server board supports two Zero Channel RAID cards: the Intel
®
SRCZCR RAID
Adapter and the Adaptec* ASR-2010S RAID adapter. This support is provided via hardware and
BIOS support only on PCI-X Slot 2. If either of these RAID cards is installed, then the SCSI
interrupts are routed to the RAID adapter instead of to the PCI interrupt controller.
Segment A: 32-bit/33 MHz PCI Subsystem
The 32-bit / 33 MHz PCI segment includes the following embedded devices and connectors:
• Three 5 V keyed full-length, full height PCI expansion slots (PCI Slots 4, 5 and 6)
• Integrated ATI Rage XL video controller with 8 MB of on-board SDRAM
32-bit/33 MHz PCI features include:
• Bus speed up to 33 MHz
• 5 V signaling environment
• Burst transfers up to a peak of 132 MB/s
• 8-, 16-, or 32-bit data transfers
• Plug-and-Play ready
• Parity enabled
Video
The system has an integrated ATI Rage XL 32-bit high-performance SVGA subsystem that
supports the following:
• BIOS compatibility with all standard VGA modes
• 8 MB of video memory
• Pixel resolutions up to 1600 x 1200 pixels per inch (ppi) in 8/16/24/32 bpp modes under 2D
and up to 1024 x 768 ppi in 8/16/24/32 bpp modes under 3D
• Both CRT and LCD monitors up to 100 Hz vertical refresh rate
Table 2. Video Modes
SE7501HG2 2D Mode Video Support
2D Mode Refresh Rate (Hz)
8 bpp 16 bpp 24 bpp 32 bpp
640x480 60, 72, 75, 90, 100 Supported Supported Supported Supported
800x600 60, 70, 75, 90, 100 Supported Supported Supported Supported
1024x768 60, 72, 75, 90, 100 Supported Supported Supported Supported
1280x1024 43, 60 Supported Supported Supported Supported
1280x1024 70, 72 Supported – Supported Supported
1600x1200 60, 66 Supported Supported Supported Supported
1600x1200 76, 85 Supported Supported Supported –
3D Mode Refresh Rate (Hz) SE7501HG2 3D Mode Video Support with Z Buffer Enabled
640x480 60, 72, 75, 90, 100 Supported Supported Supported Supported
800x600 60, 70, 75, 90, 100 Supported Supported Supported Supported
1024x768 60, 72, 75, 90, 100 Supported Supported Supported Supported
1280x1024 43, 60, 70, 72 Supported Supported – –
1600x1200 60, 66, 76, 85 Supported – – –
