Intel Server Board SE7501HG2 Product Guide
32
Minimum Hardware Requirements
To avoid integration difficulties and possible board damage, your system must meet the following
minimum requirements. For more information on supported processors and qualified memory and
chassis components, see:
http://support.intel.com/support/motherboards/server/SE7501HG2
Processor
Minimum of one Intel Xeon processor with 512K cache. For a complete list of supported
processors, see:
http://support.intel.com/support/motherboards/server/SE7501HG2
Memory
Minimum of two 128 MB ECC, DDR266-compliant registered SDRAM 184-pin gold DIMMs.
1
Power Supply
Minimum of 450 W with 1.2 A +5 V standby current (in order to support Wake On LAN
*
(WOL))
and 12+ V CPU power support [ATX], which meets the SSI EPS 12 V specification. You must
provide standby current, or the board will not boot.
For more information on the SSI EPS 12 V specification, see:
http://www.ssiforum.org
Installation Notes
Installation Process Quick Reference
Step Where the information is located
Remove the access cover Your chassis manual
Install the I/O shield Page 33
Install the standoffs Page 35
Install the rubber bumper Page 36
Install the server board Page 36
Connect cables to the server board Page 38. Refer also to your chassis manual
Install the processor and processor wind tunnel in the Intel®
Server Chassis SC5200 base chassis or in a reference chassis
Page 39
Install the processor in the Intel® Server Chassis SC5200 with
Hot Swap Redundant Power
Page 46
Install memory Page 51
1
DDR200 compliant registered ECC DIMMs can be used only if 400 MHz processors are installed.
