Description
9
Feature Description
System I/O
National Semiconductor
*
PC87417 Super I/O Controller (LPC bus) that provides
the following:
• Floppy Disk Controller
• PS/2-compatible keyboard and mouse ports, 6-pin DIN connectors
• Advanced parallel port, supporting Enhanced Parallel Port (EPP) level 1.7
and 1.9, ECP, compatible 25-pin connector
• Two serial ports: One a-synch 9-pin RS-232C, one via 10-pin internal
connector
One Ethernet controller (Intel 82546EB) providing two 1-gigabit RJ45 connections
Five USB ports: three stacked USB connectors in I/O rear panel, two via 10-pin
internal header
Power • SSI-EEB 3.0 compliant
• Power/Sleep Switch with LED Indicator
• Wake on LAN
*
(WOL)
• Wake on Ring (WOR)
Security • BIOS password
• Keyboard password protection
• Floppy write-protect
Form Factor • SSI-EEB 3.0 compliant form factor
