15
Planning Installation
4.2.3 Packing List
Before beginning installation, make sure you have all the included components.
The ADU Package & BDU Package are provided in one box.
NOTE: The SIM card is provided by the service provider and may be packaged separately.
Above Deck Unit (ADU) Package
Description Q'ty Size Remarks
Above Deck Unit (ADU) 1
370 mm x 370 mm x
270 mm
Antenna Unit
LMR200 RF Cable
(TNC/F-TNC/F Type)
1 25 m To Connect ADU - BDU
Antenna Mounting Template 1 Antenna Mounting Template
Hex Bolt 5 M6 x 20L
To Mount Antenna on Mounting Surface
(M6 Bolt Kit)
Spring Washer 5 M6
Flat Washer 5 M6
Hex Bolt 5 M10 x 20L
To Mount Antenna on Mounting Surface
(M10 Bolt Kit)
Spring Washer 5 M10
Flat Washer 5 M10
Below Deck Unit (BDU) Package
Description Q'ty Size Remarks
Below Deck Unit (BDU) 1
315 mm x 190 mm x
42 mm
Below Deck Unit
DC Power Cable 1 1 m BDU Power
Ethernet Cable (RJ45 / LAN) 1 1 m To Connect BDU to PC
Wi-Fi Antenna 1
Quick Installation Guide (QIG) 1 Quick Installation Guide
Tapping Screw 5 M5 x 16L To Fix BDU (Direct Mounting Type)
Terminal Block 1
85 mm x 40 mm x
36 mm
For Inter-connection of Cables
19-inch Rack Mount Kit (Optional)
The 19-inch Rack Mount Kit can be purchased separately. When this kit is supplied, it is packaged in the
BDU Package.
Description Q'ty Size Remarks
AC Power Cord (USA) 1 1.5 m BDU Power Cord (110 V)
AC Power Cord (CEEE7/7) 1 1.5 m BDU Power Cord (220 V)
AD-DC Adaptor 1 BDU Power Adaptor (150 W)
Rackmount Plate 1
Kit for Rackmount Plate
Pan Head Screw (with Spring
& Flat Washer)
5 M4 x 16L
Connector Tray 1
Kit for Connector Tray
Flat Head Screw 4 M3 x 6L
To Next Page
