C700 - Marine Satellite Communication System
Chapter 9. Specification
9.1 Technical Specication
Above Decks Unit (ADU)
ADU Height 270 mm (10.62")
ADU Diameter 370 mm (14.99")
ADU Weight 6.8 kg (15 lbs)
Ship's Motion
Roll ±20° at 0.4 Hz and ±15° at 0.33 Hz
Pitch ±20° at 0.45 Hz and ±30° at 0.25 Hz
Yaw ±20° at 0.45 Hz and ±10° at 0.2 Hz
Turning Rate 12°/sec
Rx
Frequency 1616 MHz ~ 1626.5 MHz
Gain 9.2 dBi
Tx
Frequency 1616 MHz ~ 1626 MHz
Gain 9.2 dBi
Polarization RHCP (Rx and Tx)
ADU to BDU Cable (Antenna Cable) Single Coaxial Cable
Below Decks Unit (BDU)
BDU Size 315 x 190 x 42 mm (12.4" x 7.48" x 1.655")
BDU Weight 1.5 kg (3.3 lbs) [stand-alone type]
LED Indicator 3 LEDs for Power, Satellite link, and Event
GNSS GPS, GLONASS, Galileo
Wi-Fi 802.11 b/g
Ethernet RJ45 LAN Ports (4 ea) including PoE Ports (2 ea)
Analog Phone (POTS) RJ14 LAN Ports (1 ea)
I/O 10 pins GPIO
Wireless 1 Wi-Fi (SMA Reverse Polarity)
Web Interface Embedded in BDU, available by Ethernet or Wi-Fi
Input Power 10.8 ~ 30 V DC
Power (max) 120 W
