16
C700 - Marine Satellite Communication System
4.3 System Cables
Make sure of the following before installing system cables.
1. All cables need to be well clamped and protected from physical damage and exposure to heat and
humidity.
2. Don't use any acutely bent cable.
3. Use watertight glands or swan neck tubes on exposed bulkheads or deck heads where the cable passes
through.
4. For installing cables longer than the recommended length, consult with Intellian Technologies rst.
4.3.1 RF Cable (Connecting ADU - BDU)
Due to the signal losses across the length of the RF coax on L-Band, Intellian recommends the following
50 coax cable types for standard system installations. Check the instructions from the cable supplier.
The table below shows the recommended cable types and maximum cable lengths for the antenna system.
Coaxial Cable
Type
@900MHz @900MHz loss 13.5 dB
Recommended
Max. Cable Length
Bend Radius
LMR200 32.6 dB/100 M 0.326 dB/1 M 38.2 M 35 M
Installation
12.7 mm (0.5 in.)
LMR300 19.9 dB/100 M 0.199 dB/1 M 62.5 M 60 M
Installation
22.2 mm (0.88 in.)
LMR400 12.16 dB/100 M 0.1216 dB/1 M 102.5 M 100 M
Installation
25.4 mm (1 in.)
* Maximum DC resistance of RF cable: 1.3
* RF loss at 900MHz: 13.5 dB incl. connector
* Optimal tightening torque for TNC-type connector: 1.5 N-m
Antenna Pole Mount Kit (Optional)
The Antenna Pole Mount Kit can be purchased separately. When this kit is supplied, it is provided in a
separate box.
Description Q'ty Size Remarks
Pole Bracket 1
Pole Tube 1
Hex Bolt 10 M6 x 20L
Spring Washer 10 M6
Flat Washer 10 M6
40A (1½ inch) Pole Bushing 1
For Mounting Aantenn on 40A (1½ inch)
Pole
Socket Set Screw 4 M12 x 12L
To Next Page
