C700 - Marine Satellite Communication System
7.4 Using PoE Devices
7.4.1 Accessing Internet
To use PoE Devices and Wireless Devices, you need to access the Internet. The network is automatically
congured by DHCP without the need for additional PC IP conguration.
1. Connect an Ethernet cable from the PoE Port 1 or PoE Port 2 on the back of the BDU to devices. The
network connection is established automatically.
2. Use the following IP address to access the Intellian AptusLX Web page.
• IP Address: 192.168.200.1 (Default)
3. Log into the AptusLX Web by typing in a user name and password information. If this system has not
been changed from the factory default:
• User Name: intellian
• Password: 12345678
4. Select the SETTING on the main menu then go to the Network
Port menu.
5. Toggle PoE button to the ON position on the port 1 or port 2. If you don't want to use PoE connection,
choose the OFF position.
6. Select the LAN from the Port Type drop-down list.
7. Click the Apply button to apply the settings to the system.
1
2
4
3
7.5 Using Wireless Devices
7.5.1 Installing Mobile Application
To be able to use a mobile phone you must install a compatible mobile application. Intellian recommends
using the following mobile application:
Grandstream Wave App
• App Store: https://itunes.apple.com/us/app/grandstream-wave/id1029274043?ls=1&mt=8
• Google Play: https://play.google.com/store/apps/details?id=com.grandstream.wave
