Planning Installation

Figure 8: Unpacking ADU Package

2. Take out the ADU package including an Antenna Mounting Template, an ADU Bolt Kit, an RF Cable, and

an ADU Unit.

ADU Unit

ADU Bolt Kit

RF Cable

Antenna Mounting

Template
