102 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
4.1.n.6.27 Sensor type
27 Sensor type
>Low temp.<
The events reported by a technical zone depend on the type of the sensor
connected. The Sensor type option specifies what is the sensor and what events
it should report. The following sensor types are available:
• Low temperature detector
• High temperature detector
• Gas detector
• Water detector
• Fire alarm
• Generic
Table 26 below lists events that may be reported for each sensor type.
Table 26: Sensor types and reported events
See also “Reporting codes used in Advisor Advanced” on page 223.
4.1.n.6.28 Virtual zone
The menu allows mapping the selected zone to an existing output.
If an output is not set, the zone state follows the state of the physical input
assigned.
If an output is selected, the zone becomes a virtual zone that is active, when the
selected output is active. In this case the physical input has no effect on the
zone.
