58 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
1.2.8.1 PIN status
The PIN status is an informational screen that lets you verify the PIN acceptance
status. The status can be one of the following:
• Normal: Accepted by the SIM.
• Unknown: The status is unknown.
• One trial left! The SIM card provides the last attempt for the correct PIN.
• PUK required! The SIM card is locked after three unsuccessful PIN entering
attempts, until the PUK will be provided.
You can only unlock the SIM card by inserting it in a standard cell phone and
providing the PUK. There is no possibility to enter the PUK in the Advisor
Advanced system.
1.2.8.3 GSM net.reg.
3>GSM net.reg.
Home network
The GSM network registration state can be one of the following:
• Inactive: The dialler has not registered in the network, and is not searching
nor connecting
• Home network: Registered in the home network
• Searching: Searching for the network to register
• Reg. denied: Registration to the network has been denied
• Unknown: Registration state is unknown
• Roaming: Registered to a network in roaming
1.2.8.4 GPRS net.reg.
4>GPRS net.reg.
Home network
The GPRS network registration state can have the same values as described in
“1.2.8.3 GSM net.reg.” above.
1.2.8.5 GPRS state
5>GPRS net.reg.
Home network
The GPRS network state can be one of the following:
• Not available: GPRS functionality is not available.
• No network: GPRS functionality is available, but no network is present (for
example, SIM card is absent).
• Not established: GPRS functionality is available, but connection is not
established (IP parameters are not assigned).
• Configured: GPRS functionality is available and connection is established.
