Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 69
2.2.1.n.2 Keypad address
The bus address is an informational screen showing the bus address set by DIP
switches or programmed within the keypad.
2.2.1.n.3 Keypad options
The Keypad options menu contains the shown below, which are necessary to
configure the selected keypad.
Note: The available options depend on the keypad type.
2.2.1.n.3.1 Keypad name
Use the Keypad name option to enter a name that identifies the keypad to the
end-user.
When a keypad is created, it is given the default name “Keypad <n>”, where <n>
is the keypad number. Enter this menu to edit the current name.
A keypad name can consist of 16 characters.
2.2.1.n.3.2 Tamper area
The Tamper area option determines which area receives keypad tamper and
fault events. To change it, select the area and press Enter.
2.2.1.n.3.3 View areas
The View areas menu lets you specify which area will display information on this
keypad without a user authorization. The areas are displayed as a list. To change
the selection, press Enter and select the appropriate areas.
Note: After an authorization the area view depends on the user privileges and
system state.
How to select areas to view
See “How to edit a list” on page 39.
Note: After changing this list, the control of selected areas is also enabled (see
“2.2.1.n.3.4 Control areas” on page 70).
