8BChapter 9: Live view
TruVision DVR 11 and DVR 11c User Manual 69
• Manually change the video output format (PAL/NTSC)
• Change the time out period after which the display reverts to showing live
view
• Enable/disable the transparency of the menus on screen
• Enable/disable whether the status icons appear on screen
See Figure 21 and Table 14 on page 69 for the general options available, and
Figure 22 and Table 15 on page 70 for further options.
The changes are immediately implemented once Apply is clicked to save the
settings.
Figure 21: Monitor setup window: General settings
Table 14: Description of the Monitor setup window: General settings
Define the language of the system.
Select the desired language from the drop-down list and click
Apply. The language displayed changes immediately.
Define the DVR name. The default name is TVR 11.
Click the edit box and enter the new name from the soft keyboard.
The device number to use for the DVR when programming the
remote control or keypad. The default value is 255.
Each DVR in a daisy chain must have a unique zone ID so that it
can be controlled by a KTD-405 keypad.
The default value is 1.
esolution Define the resolution of the selected monitor.
Select one of the options from the drop-down list and click Apply.
The selected resolution must be the same as that of the monitor.
required Define whether a login password is required.
Check the box to enable/disable, and click Apply.
output video Enable/disable the monitor display of the main and auxiliary monitor
size to accommodate for differently sized monitors.
Check the box to enable/disable, and click Apply.
