90 Intermec EasyCoder ESim v4.00—Programmer’s Reference Manual
Chapter 7—Commands
Q – Set Form Length (gap or slot), cont.
Examples Rectangular label (203.2 dpi = 8 dots/mm printhead):
p
1
= 20.0 mm(160 dots)
p
2
= 3.0 mm (24 dots)
The Q command would be:
Q160,24↵
Butterfl y label (203.2 dpi = 8 dots/mm printhead):
p
1
= 12.5 mm (100 dots)
p
2
= 3.0 mm (24 dots)
p
3
= 3.0 mm (24 dots)
The Q command would be:
Q100,24+24↵
p
p
p
PRINT
DIRECTION
1
2
3
p
p
1
2
