Intermec PB22 User Manual

1
1
Using the PB22 and PB32 Mobile Label
and Receipt Printer
Use this chapter to familiarize yourself with the PB22 and
PB32 mobile label and receipt printer. This chapter contains
these sections:
• Introducing the PB22 and PB32 Mobile Label and
Receipt Printer
• Using the Batteries
• Loading Media
• Printing on Floodcoated Media
• Understanding the Display Modes
• Printing a Test Page

Intermec PB22 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Battery type	Built-in battery
Battery voltage	7.2 V
Bundled software	IPL, Fingerprint, ZSim (ZPLII Simulation), ESC-P, DSim
Media types supported	Labels
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	176 mm
Width	101 mm
Height	71 mm
Weight	678 g
