Chapter 3 — Troubleshooting and Maintaining the PB22 and PB32
64 PB22 and PB32 Mobile Label and Receipt Printer User Guide
5 Repeat Steps 3 and 4 if necessary.
6 Allow the printhead to dry for a minute or more before loading a
new supply of media and ribbon.
Cleaning the Platen Roller
Regular cleaning of the platen roller every five rolls of media prolongs
the life of the printhead and ensures that you maintain high print
quality.
Clean the printhead with the cleaning swab. The cleaning swab is
shipped with the printer and can also be purchased separately from
www.intermec.com.
To clean the platen roller
• Rotate the platen roller and clean it thoroughly with the cleaning
swab.
Be sure to clean these parts using the cleaning swab:
• Paper sensors
• Tear bar
Cleaning the Printer Exterior
Make sure to keep the exterior of the printer clean, this will reduce the
risk of dust or foreign particles reaching the inside of the printer and
affect printer functionality.
To clean the printer exterior
1 Close the media cover.
2 Use a soft cloth, possibly moistened with water or a mild detergent
and wipe the printer exterior.
Make sure to keep the surface surrounding the printer clean as
well.
Note: The cleaning swab is the recommended method for cleaning the
printhead and platen roller. Using other methods for cleaning may
damage the printer.

Intermec PB22 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Battery type	Built-in battery
Battery voltage	7.2 V
Bundled software	IPL, Fingerprint, ZSim (ZPLII Simulation), ESC-P, DSim
Media types supported	Labels
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	176 mm
Width	101 mm
Height	71 mm
Weight	678 g
