Intermec PB22 User Manual

Chapter 2 — Configuring the PB22 and PB32
48 PB22 and PB32 Mobile Label and Receipt Printer User Guide
Upgrading the Printer Firmware Using the Printer Home Page
You can upgrade your printer using the printer home page with a
printer with an 802.11 radio running IPL or Fingerprint.
To upgrade using the printer home page
1 Establish a connection between your printer and the network. For
help, see “Setting Up 802.11 Radio Communications” on
page 35.
2 Establish a connection between your PC and the network your
printer is on.
3 Download the firmware upgrade file (.bin) to your PC:
a Go to www.intermec.com.
b Click Support > Downloads.
c Use the Product Category, Product Family, and Product
fields, to select the printer model.
d Click Submit. The available software appears.
e Download the latest firmware version to your PC.
f Extract the .zip file to a folder on your PC.
4 If you are using Fingerprint or IPL, use the display to find the
printer’s IP address:
a Press the Setup button.
b Press until you reach Network.
c Press to enter the Network menu.
d Press until you reach IP Address.
e Press to select and view the IP Address.
f Press the Setup button to exit the menu.
5 Start a web browser.

Intermec PB22 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Battery type	Built-in battery
Battery voltage	7.2 V
Bundled software	IPL, Fingerprint, ZSim (ZPLII Simulation), ESC-P, DSim
Media types supported	Labels
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	176 mm
Width	101 mm
Height	71 mm
Weight	678 g
