Chapter 1 — Using the PB22 and PB32 Mobile Label and Receipt Printer
24 PB22 and PB32 Mobile Label and Receipt Printer User Guide
3 Release both buttons. The printer performs a test feed (sensor
calibration), prints, and then enters Dump mode.
The printer is now in Dump mode and it scans the
communication ports. Any characters received on the
communication ports are printed.
4 Press Feed to exit Dump mode.
After you exit Dump mode, the printer returns to Ready mode. For
more information on Dump mode, see “Troubleshooting
Communication Problems” on page 60.
Using Extended Test Mode
Use Extended Test mode to run additional diagnostic tests, enter
Dump mode, or reset the printer to factory defaults.
Sample Extended Test Mode Screen
To enter Extended Test mode
1 Make sure that the printer is loaded with media.
2 Press the media cover release button to open the media cover.
3 Press the Standby button to turn the printer off.
4 Press Feed and Standby buttons at the same time until CLOSE
PRINTER DOOR appears on the screen.
5 Close the media cover. You are now in Extended Test mode:
• Press to cycle through the options.
• Press to select a test option.
• Press to exit Extended Test mode.
OK
TEST LABELS
CHESS

Intermec PB22 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Battery type	Built-in battery
Battery voltage	7.2 V
Bundled software	IPL, Fingerprint, ZSim (ZPLII Simulation), ESC-P, DSim
Media types supported	Labels
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	176 mm
Width	101 mm
Height	71 mm
Weight	678 g
