Intermec PB22 User Manual

Chapter 3 — Troubleshooting and Maintaining the PB22 and PB32
PB22 and PB32 Mobile Label and Receipt Printer User Guide 63
PB22 and PB32 Mobile Label and Receipt Printer: You need to clean these
parts regularly.
Cleaning the Printhead
Clean the printhead every five rolls of media to prolong the life of the
printhead and ensures that you maintain high print quality.
Clean the printhead with the cleaning swab. The cleaning swab is
shipped with the printer and can also be purchased separately from
www.intermec.com.
To clean the printhead
1 Open the media cover.
2 Remove the media and ribbon.
3 Use the cleaning swab or cleaning pen to dissolve any
contamination on the line of heat-emitting objects at the front/
bottom of the printhead.
4 Wait 30 seconds and carefully rub off any contamination.
Use only the cleaning agents specified in this section. Intermec
is not responsible for damage caused by any other cleaning
materials used on this printer.
Tear bar
Paper sensor
Platen roller
Printhead
Note: The cleaning swab is the recommended method for cleaning the
printhead and platen roller. Using other methods for cleaning may
damage the printer.

Intermec PB22 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Battery type	Built-in battery
Battery voltage	7.2 V
Bundled software	IPL, Fingerprint, ZSim (ZPLII Simulation), ESC-P, DSim
Media types supported	Labels
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	176 mm
Width	101 mm
Height	71 mm
Weight	678 g
