Intermec PB22 User Manual

Chapter 1 — Using the PB22 and PB32 Mobile Label and Receipt Printer
14 PB22 and PB32 Mobile Label and Receipt Printer User Guide
Extending Battery Life
Follow these guidelines to extend the overall life of your battery:
• Never expose the battery to direct sunlight or temperatures over
50 °C (122 °F).
• Only charge the battery inside the printer using a power supply or
in the 4-bay battery charger (Model AC18).
• Do not set the backlight to always on. The always on setting
disabled automatic power saving modes.
Follow these guidelines to extend the life of your battery between
charges:
• Press the Standby button to put the printer in Standby mode.
• Remove the battery if you do not need to use the printer for three
days or more.
• Do not operate the printer when the ambient temperature is
-20 °C (-4 °F) or lower.
Using the printer in temperatures below
freezing reduces the overall battery life.
Battery charging error. You may need to replace the battery.
External power connected and there is no battery in the printer.
Battery Icon Status (continued)
Icon Status
Note: Rechargeable batteries lose their ability to maintain a charge
over time. You can only recharge a battery a finite number of times
before you must replace it.

Intermec PB22 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Battery type	Built-in battery
Battery voltage	7.2 V
Bundled software	IPL, Fingerprint, ZSim (ZPLII Simulation), ESC-P, DSim
Media types supported	Labels
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	176 mm
Width	101 mm
Height	71 mm
Weight	678 g
