Intermec PB22 User Manual

Chapter 1 — Using the PB22 and PB32 Mobile Label and Receipt Printer
PB22 and PB32 Mobile Label and Receipt Printer User Guide 5
All of the buttons can act as “soft keys,” which means that the
function of each button depends on the state of the printer. A small
icon appears in the screen next to the button to indicate the function
it performs.
Info Press to display a summary of network connection
information and error conditions. Each setting in the
summary information displays on the screen for five
seconds.
In Fingerprint and IPL, press this button in Pause
mode to cancel the print job. The info button is not
functional with ESC/P.
Understanding the Soft Keys
Button Soft Keys Description
• Moves up one level in the menu system. This soft
key appears in Setup mode.
• Increases the value of a number when editing
settings such as an IP address. This soft key
appears in Setup mode.
• Pauses the printing job. This icon appears only
when you are printing.
Exit Setup mode and return to Ready mode.
Moves through the settings at the same level in the
menu system.
• Moves down one level in the menu system and
saves changes to a setting.
• Exits a printing job or exits Information mode.
How to Use the PB22 and PB32 Buttons (continued)
Name Button Function
mm

Intermec PB22 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Battery type	Built-in battery
Battery voltage	7.2 V
Bundled software	IPL, Fingerprint, ZSim (ZPLII Simulation), ESC-P, DSim
Media types supported	Labels
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	176 mm
Width	101 mm
Height	71 mm
Weight	678 g
