Intermec PB22 User Manual

Chapter 1 — Using the PB22 and PB32 Mobile Label and Receipt Printer
PB22 and PB32 Mobile Label and Receipt Printer User Guide 9
8 Cold boot the printer:
a Remove the printer battery.
b Replace the printer battery.
c Turn the printer on.
To change the printer language using the display and IPL
1 Press the Setup button. The Setup menu system appears.
2 Press until you reach Test/Service.
3 Press to enter the Test/Service menu system.
4 Press until you reach CMD Language.
5 Press to enter the CMD Language menu system.
6 Press until you see the language you want to select.
7 Press to select the language.
8 Cold boot the printer:
a Remove the printer battery.
b Replace the printer battery.
c Turn the printer on.
To change the printer language using the display and ESC/P
1 Make sure the printer is in Ready mode.
2 Turn the printer off.
3 Open the media door.
4 Press and hold the Feed and Power buttons until the display
shows “Close Printer Door.”
5 Press until you reach CMD Language.
6 Press .
7 Press and hold the Power button until the different command
languages scroll automatically.
8 Press to select the printer language. The printer reboots.

Intermec PB22 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Battery type	Built-in battery
Battery voltage	7.2 V
Bundled software	IPL, Fingerprint, ZSim (ZPLII Simulation), ESC-P, DSim
Media types supported	Labels
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	176 mm
Width	101 mm
Height	71 mm
Weight	678 g
