INVT Goodrive300-21 Series

Goodrive300-21 integrated machine for air compressor Commissioning guidelines
-14-
AC power
R, S, T through
hole
Main motor
U1, V1, W1 through
hole
Through hole of
controlling cable
Through hole of
optional parts
cable
Through hole of
controlling cable
Fan
U2, V2, W2, ground wire
through hole
Ground wire
through hole
Through hole of
ground wire
Ventilation hole at the
bottome of the integrated
machine
Figure 4-4 Bottom view for 45–90kW
Figure 4-5 Front wiring diagram for 45–90kW
