INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Function description
-24-
Function
code
Name
Description
Default
Modify
9–11: Reserved
Note: A frequency and B frequency cannot
be set to the same frequency reference
mode. Frequency source can be set by
P00.09.
P00.08
Reference object of
B frequency
command
0: Max. output frequency
1: A frequency command
0
○
P00.09
Combination mode
of setting source
0: A
1: B
2: (A+B)
3: (A- B)
4: Max(A, B)
5: Min. (A, B)
0
○
P00.10
Frequency set
through keypad
0.00 Hz–P00.03 (Max. output frequency)
50.00Hz
○
P00.11
ACC time 1
0.0–3600.0s
Model
depended
○
P00.12
DEC time 1
0.0–3600.0s
Model
depended
○
P00.13
Running direction
0: Run at the default direction.
1: Run at the opposite direction.
2: Disable reverse running
2
○
P00.14
Carrier frequency
1.0–15.0kHz
Model
depended
○
P00.15
Motor parameter
autotuning
0: No operation
1: Rotary autotuning
2: Static autotuning 1 (all-around autotuning)
3: Static autotuning 2 (partial autotuning)
0
◎
P00.16
AVR function
selection
0: Disable
1: Valid during the whole procedure
1
○
P00.17
Inverter type
0: G type
1: P type
0
◎
P00.18
Function parameter
restore
0: No operation
1: Restore default values
2: Clear fault records
3–6: Reserved
0
◎
