Goodrive300-21 integrated machine for air compressor Function description
-25-
Function
code
Name
Description
Default
Modify
7: Parameter 1 for customer 1
8: Parameter 2 for customer 1
9: Parameter for customer 2
10: Parameter for customer 3
Note: When the factory setting is restored, the
motor parameters in group P02 keep the
current value unchanged. In addition, the
values of P05.38, P05.40, P05.48, P05.50 in
group P05, and P18.04, P18.28, P18.29,
P18.32, P18.33, P18.38 in group P18 remain
unchanged.
P01.01
Starting frequency
of direct start
0.00–50.00Hz
0.50Hz
◎
P01.08
Stop mode
0: Decelerate to stop
1: Coast to stop
0
○
P01.15
Stop speed
0.00–100.00Hz
0.50Hz
◎
P01.16
Stop speed
detection mode
0: Detect by the setting value of the speed
(determine the ramps frequency)
1: Detect by the feedback value of the speed
(valid only for vector control)
1
◎
P01.17
Feedback speed
detection time
0.00–100.00 s (valid when P01.16=1)
0.50s
◎
P02.00
Type of motor 1
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0
◎
P02.01
Rated power of AM
1
0.1–3000.0kW
Model
depended
◎
P02.02
Rated frequency of
AM 1
0.01Hz–P00.03 (Max. output frequency)
50.00Hz
◎
P02.03
Rated speed of AM
1
1–36000rpm
Model
depended
◎
P02.04
Rated voltage of AM
1
0–1200V
Model
depended
◎
P02.05
Rated current of AM
1
0.8–6000.0A
Model
depended
◎
P02.06
Stator resistance of
AM 1
0.001–65.535Ω
Model
depended
○
P02.07
Rotor resistance of
AM 1
0.001–65.535Ω
Model
depended
○
