Page #118 background image
IPE300 series engineering VFD Basic operation guidelines
-107-
Function
code
Name
Description
Default
(signed)
17: Low-order bit of position feedback
(unsigned)
18: Position feedback setting flag (position
feedback can be set only after this flag is
set to 1 and then to 0)
19–20: Reserved
21: Control word 2
22: Set frequency (x100, Hz, with sign,
-Fmax – Fmax)
23: Set rotation speed (x1, rpm, without
sign, 0–60000)
24: Set rotation speed (x1, rpm, with sign,
-30000–30000)
25: Auxiliary frequency setting (x100, Hz,
with sign, -50.00Hz – 50.00Hz)
26: Auxiliary torque setting (x10, %, with
sign, -50.0% – 50.0%)
27: Reduction rate of drop control (x100,
Hz, 0.00 – 50.00Hz)
28: Number of slaves (0–15, valid when
the VFD is the master in master-slave
control mode)
29–47: Reserved
Similarly, sent PZD programming can be completed through P15.13–P15.23.
5.5.17.4 Free conversion of process data base values
Take received PZD2 as an example: Data received internally by VFD = Received PZD *
P91.00/P91.01
Function
code
Name
Description
Default
P91.00
Numerator of received PZD2
conversion base value
Actual
received
value
Received
PZD
Denominator of received PZD2
conversion base value
Numerator of received PZD
conversion base value
x
=
16384
P91.01
Denominator of received
PZD2 conversion base value
16384
