INVT IPE300 Series User Manual

IPE300 series engineering VFD Installation guidance
-17-
Environment
Condition
Relative
humidity (RH)
 RH: less than 90%
 Condensation is not allowed.
 The max. RH cannot exceed 60% in the environment where there are
corrosive gases.
Storage
temperature
-30–+60°C
Running
environment
Install the VFD in a place:
 Away from electromagnetic radiation sources
 Away from oil mist, corrosive gases, and combustible gases
 Without the chance for foreign objects such as metal powder, dust, oil and
water to fall into the VFD (do not install the VFD onto combustible objects such
as wood)
 Without radioactive substances and combustible objects
 Without hazard gases and liquids
 With low salt content
 Without direct sunlight.
Altitude
 Lower than 1000 meters
 When the altitude exceeds 1000m, derate by 1% for every additional 100m.
 When the installation site altitude exceeds 3000m, consult the local INVT
dealer or office.
Vibration
The max. amplitude of vibration cannot exceed 5.8m/s
2
(0.6g)
Installation
direction
Install the VFD vertically to ensure good heat dissipation performance.
Note:
 The VFD must be installed in a clean and well-ventilated environment based on the housing IP
rating.
 The cooling air must be clean enough and free from corrosive gases and conductive dust.
4.2.2 Installation direction
The VFD can be installed on the wall or in a cabinet.
The VFD must be installed vertically. Check the installation position according to following
requirements. For details about the outline dimensions, see Appendix C Dimension drawings.
